Internally threaded sleeve

Steel sleeve with internal thread for chemical anchor with thread diameter from M6 to M12 The sleeve with internal thread is a component of the chemical anchor used in all assembly situations in which it is required to dismantle the mounted element.

APPLICATION:

The sleeve can be used for all substrates, both solid, such as: concrete and stone, and with empty spaces: porotherm, perforated brick, silicon, floor blocks, etc. When installing in hollow substrates, it should be used together with a plastic or steel sleeve mesh with appropriate dimensions (TPS, TMS) Internal threaded sleeves are used in conjunction with a metric screw of appropriate diameter, threaded rod or threaded pin.

BENEFITS:

  • option to disassemble the anchored element and then reassemble it
  • can be used for all substrates (use of a mesh sleeve is recommended for porous materials)
Category:
Description
Product Details
Downloads

Product Code Thread Diameter (mm) Outer Diameter of Sleeve (mm) Drill Hole Diameter (mm) Sleeve Length (mm) Box Packing Outer Packing
TIS06 6 8 10 50 100 1000
TIS08 8 12 12 80 50 500
TIS10 10 14 16 80 50 250
TIS12 12 16 18 80 25 25
